KJLC 1500 Series Diaphragm Manometers

Lesker KJLC 1500 Series Diaphragm Manometers

A Kurt J. Lesker compact and accurate unit for measuring the absolute pressure of any gas or liquid that does not attack 304/316 stainless steels (stainless diaphragm version) or 304 stainless steel/silicon (silicon diaphragm version).

Features

• Sensors are available in a wide variety of flange and tube terminations
• Includes 10' sensor cable and 6' line cord
• Sensor can withstand prolonged bakeout to 100° C

We offer three options for the electronics:

• Indicator only (no set-points)
• Controller (with 2 set-points)
• Active Switch with transmitter (1 set-point)

Indicator & Controller Features:

• 3-1/2 digit LCD displays reading in Torr (standard), or mbar (optional)
• Accurate, high-resolution digital measurement for about the same cost as analog devices

Active Switch

• Plugs directly onto the diaphragm manometer tube, providing an inexpensive means to control your vacuum system
• Use switch to control backfill pressure on pumping and purge operations, or connect the output to a PC/PLC for digital control driven by the output signal

NOTES: Diaphragm manometer gauge tube sold separately. Power supply and diaphragm manometer gauge tube sold separately.

Lesker KJLC 1500 Series Diaphragm Manometers
